Model : ZXRHF0008
Material ; PVC , ABS or PET etc
Frequency : 13.56Mhz
Chip : NXP MIFARE Ultralight®EV1
Size: 85.5*54mm , 0.84mm thickness
Color : offset printing full color or white without printing
Certificate ;RoHS
MOQ :1000pcs
Free samples testing is available
Functional Specification :
1: FEATURES
Full ISO /IEC 14443 A 1-3 compliant
106kbit/s communication speed
Anti-collision support
1536 bits(192 bytes) EEPROM memory
Protected data access via 3DES authentication
Cloning protection
Command set compatible to MIFARE Ultralight
Memory structure as in MIFARE Ultralight ( pages )
16 bit counter
Unique 7 bytes serial number
Number of single write operations : 10.000
2:Key Applications
Public transportation
Event ticketing
Loyalty
NFC Forum tag type 2
What can our products do?
You may need our products if you are related with RFID Solution company, NFC solution company, Security
Company, Music or festival event company, IOT company, Smart Card manufacturer, RFID card or NFC card
company, NFC Tag company, rfid pet tag company, RFID System company, RFID Solution provider,etc.
Statement: Pictures above only show the product , the intellectual property rights of the logo owned by their trademark companies.
Full color printing MIFARE Ultralight C represents a new security concept to the contactless limited-use market. With its 3DES authentication ,MIFARE Ultralight C reflects the trend of enhanced security in contactless applications .Nowadays many solution providers eliminate double infrastructure where MIFARE Ultralight C provides the perfect solution for a complete contactless system. It can easily be integrated in existing MIFARE DESFire installations ,re-suing similar authentication commands ,Shenzhen Zhixin RFID Tag Co.,Ltd offers high performance MIFARE Ultralight C rfid cards ,labels , wristband .etc . we can offer you color printing , engraving nunbers , barcode .etc .
| Product | Full Color Printing MIFARE Ultralight C 13.56Mhz RFID Cards |
| Material | PVC, ABS, PET |
| Size | Stander size(credit card size):85.5*54*0.84mm or customized |
| Surface Finishing | Glossy/Matte/Frosted/Transparent |
| Printing | Without printing, with lamination overlay |
| Chips Option | MIFARE Ultralight® C MIFARE Plus® S 2K / S 4K ,MIFARE Plus® X 2K / X 4K MIFARE Plus® X 2K / X 4K,NXP MIFARE Classic®1k ICODE® SLIX, ICODE® SLIX-S, ICODE® SLIX-L, ICODE® SLIX 2 NTAG® 213,NTAG® 215,NTAG® 216 MIFARE® DESFire® EV1 2K/4K/8K NXP MIFARE Classic®4K are available |
| Memory | 1536 bits ,1Kbyte ,4k byte ,,2Kbyte ,8k byte . 144bytes , etc |
| Reading distance | 3-8cm |
| Personalization | Serial number, barcode, magnetic stripe, QR code, encoding, etc |
| Package | In smaller white box, then in carton |
| Shipment | By Express, by air, by sea |
| Application | public transport tickets ,event tickets ,etc |
Functional Specification :
1: FEATURES
Full ISO /IEC 14443 A 1-3 compliant
106kbit/s communication speed
Anti-collision support
1536 bits(192 bytes) EEPROM memory
Protected data access via 3DES authentication
Cloning protection
Command set compatible to MIFARE Ultralight
Memory structure as in MIFARE Ultralight ( pages )
16 bit counter
Unique 7 bytes serial number
Number of single write operations : 10.000
2:Key Applications
Public transportation
Event ticketing
Loyalty
NFC Forum tag type 2
