Model : ZXRHF0005
Material ; PVC , ABS or PET etc
Frequency : 13.56Mhz
Chip : NXP MIFARE Plus®S 1k , MIFARE Plus®S 2k /S4k ,
MIFARE Plus®X 2K/ X 4K
Size: 85.5*54mm , 0.84mm thickness
Color : offset printing full color or white without printing
Certificate ;RoHS
MOQ :1000pcs
Free samples testing is available
Functional Specification :
1: FEATURES
2 kB or 4 kB EEPROM
Simple fixed memory structure compatible with MIFARE Classic 1K and MIFARE Classic 4K
Memory structure identical to MIFARE Classic 4K (sectors, blocks)
Access conditions freely configurable
Supports ISO/IEC 14443-3 UIDs (4-byte UID, 4 Byte NUID, 7-byte UID), optional support of random IDs
Multi-sector authentication, Multi-block read and write
AES-128 used for authenticity, confidentiality and integrity
Anti-tearing mechanism for writing AES keys
Keys can be stored as MIFARE CRYPTO1 keys (2 × 48-bit per sector) and as AES keys (2 × 128-bit per sector)
Full support of virtual card concept
Proximity check
Communication speed up to 848 kbit/s
Number of single write operations: 200000 cycles (typical)
Common Criteria Certification: EAL4+
2： Target Applications
Public transportation
Access management such as employee, school or campus cards
Electronic toll collection
Closed loop micro payment
Car parking
Internet cafés
Loyalty programs
What can our products do?
You may need our products if you are related with RFID Solution company, NFC solution company, Security
Company, Music or festival event company, IOT company, Smart Card manufacturer, RFID card or NFC card
company, NFC Tag company, rfid pet tag company, RFID System company, RFID Solution provider,etc.
Statement: Pictures above only show the product , the intellectual property rights of the logo owned by their trademark companies.
Printable High Security MIFARE DESFire 13.56mhz RFID Smart Cardis base on iso 14443a protocol and 13.56mhz frequency with MIFARE Plus® serial IC . It brings benchmark security to mainstream contactless smart card applications and only mainstream IC compatible with MIFARE Classic®1k and 4K which
offers an upgrade path for existing infrastructure and after the security upgrade, MIFARE Plus uses AES-128 (Advanced Encryption Standard) for authentication, data integrity and encryption. MIFARE Plus is based on open global standards for both air interface and cryptographic methods at the highest security level. Normally MIFARE Plus is available in two versions : MIFARE Plus X and MIFARE Plus S . Shenzhen Zhixin RFID Tag Co.,Ltd can offer rfid card , rfid wristband , rfid and nfc label with printing , serial number , barcode ,etc . More details please contact us now .
| Product | Printable High Security MIFARE DESFire 13.56mhz RFID Smart Card |
| Material | PVC, ABS, PET |
| Size | Stander size(credit card size):85.5*54*0.84mm or customized |
| Surface Finishing | Glossy/Matte/Frosted/Transparent |
| Printing | Without printing, with lamination overlay |
| Chips Option | MIFARE Plus® S 2K / S 4K ,MIFARE Plus® X 2K / X 4K MIFARE Plus® X 2K / X 4K,MIFARE Ultralight® ICODE® SLIX, ICODE® SLIX-S, ICODE® SLIX-L, ICODE® SLIX 2 NTAG® 213,NTAG® 215,NTAG® 216 MIFARE® DESFire® EV1 2K/4K/8K NXP MIFARE Classic®4K NXP MIFARE Classic®1k are available |
| Memory | 4k byte , 1Kbyte ,2Kbyte ,8k byte . 144bytes , etc |
| Reading distance | 3-8cm |
| Personalization | Serial number, barcode, magnetic stripe, QR code, encoding, etc |
| Package | In smaller white box, then in carton |
| Shipment | By Express, by air, by sea |
| Application | car parking , Electronic toll collection,Loyalty programs,etc |
Functional Specification :
1: FEATURES
2 kB or 4 kB EEPROM
Simple fixed memory structure compatible with MIFARE Classic 1K and MIFARE Classic 4K
Memory structure identical to MIFARE Classic 4K (sectors, blocks)
Access conditions freely configurable
Supports ISO/IEC 14443-3 UIDs (4-byte UID, 4 Byte NUID, 7-byte UID), optional support of random IDs
Multi-sector authentication, Multi-block read and write
AES-128 used for authenticity, confidentiality and integrity
Anti-tearing mechanism for writing AES keys
Keys can be stored as MIFARE CRYPTO1 keys (2 × 48-bit per sector) and as AES keys (2 × 128-bit per sector)
Full support of virtual card concept
Proximity check
Communication speed up to 848 kbit/s
Number of single write operations: 200000 cycles (typical)
Common Criteria Certification: EAL4+
2： Target Applications
Public transportation
Access management such as employee, school or campus cards
Electronic toll collection
Closed loop micro payment
Car parking
Internet cafés
Loyalty programs
3:What the difference between MIFARE Plus X and MIFARE Plus S .
The MIFARE Plus X offers more flexibility to optimize the command flow for speed and confidentiality .It offers a rich feature set including proximity
checks against relay attacks
The MIFARE Plus S is the standard version for straight forward migration of MIFARE Classic® system . It is configured to offer high data integrity .
4: What information you should offer us before you want to order to us for MIFARE Plus® RFID Cards .
You may tell us chip should be MIFARE Plus® S or X
How about chip memory , because we have 2k byte and 4k byte optional support
7 byte UID or 4 byte UID as optional support of random IDs .
Do they need to print or not
