Model : ZXRLF0002
Material ; PVC , ABS or PET etc
Frequency : 125-134.2khz
Chip : EM4305 ,EM4200 ,TK4100 ,T5577 ,etc .
Size: 85.5*54mm , 0.84mm thickness
Color : offset printing full color or white without printing
Certificate ;RoHS
MOQ :1000pcs
Free samples testing is available
Features ：
512bit EEPROM organized in 16 words of 32bit
32 bit unique identifier (UID)
32 bit password read and write protection
ISO 11784/11785 Standard Compliant
Lock feature converts EEPROM words into Read only
Two data encodings : Manchester and Bi-phase
Multi-purpose data rate : 8 ,16 ,32,40 and 64 RF clocks
Reader Talk First feature
Compatible with EM4469/EM4569 communication protocol
100 to 150KHz frequency range
On-chip rectifier and voltage limiter
No external supply buffer capacitor needed
-40°C to +85°C temperature range
Very low power consumption
Applications
Animal identification according to ISO FDX-B
Pigeon races standard
Waste management standard (BDE)
Access control
Industrial
What can our products do?
You may need our products if you are related with RFID Solution company, NFC solution company, Security
Company, Music or festival event company, IOT company, Smart Card manufacturer, RFID card or NFC card
company, NFC Tag company, rfid pet tag company, RFID System company, RFID Solution provider,etc.
Statement: Pictures above only show the product , the intellectual property rights of the logo owned by their trademark companies.
EM4305 proximity rfid id cards is a CMOS integrated circuit intended for use in electronic Read/Write RF card. It is suitable for low cost solutions like animas tagging applications ,and also supports bi-phase and Manchester data encodings .We can help you to print your artwork , numbering , holes punching , barcode .etc .
| Product | 125khz EM4305 Proximity RFID ID Cards |
| Material | PVC, ABS, PET |
| Size | Stander size(credit card size):85.5*54*0.84mm or customizedClamshell LF card will 1.8mm thickness |
| Surface Finishing | Glossy/Matte/Frosted/Transparent |
| Printing | Without printing, with lamination overlay |
| Chips Option | TK 4100, EM 4200, EM 4305, T5577, HID, HITAG 1, HITAG 2, HITAG S, etc |
| Memory | 64bits , 128bits , 330bits ,2kbits . 256bits .etc |
| Reading distance | 3-8cm |
| Personalization | Serial number, barcode, magnetic stripe, QR code, encoding, etc |
| Package | In smaller white box, then in carton |
| Shipment | By Express, by air, by sea |
| Application | Door control access , identification , hotel card , member card etc .. |
Features ：
512bit EEPROM organized in 16 words of 32bit
32 bit unique identifier (UID)
32 bit password read and write protection
ISO 11784/11785 Standard Compliant
Lock feature converts EEPROM words into Read only
Two data encodings : Manchester and Bi-phase
Multi-purpose data rate : 8 ,16 ,32,40 and 64 RF clocks
Reader Talk First feature
Compatible with EM4469/EM4569 communication protocol
100 to 150KHz frequency range
On-chip rectifier and voltage limiter
No external supply buffer capacitor needed
-40°C to +85°C temperature range
Very low power consumption
Applications
Animal identification according to ISO FDX-B
Pigeon races standard
Waste management standard (BDE)
Access control
Industrial
